P800-0.8m Ku Band Cutting Parabolic Satellites Dish Antenna

SATA, that is, Shaanxi Academy of Aerospace Technology Application Co., Ltd. was founded in 1994. After 30 years of innovation and development, SATA has become the leading satellite ground application system solution provider and one of the most powerful aerospace technology application equipment manufacturers in China. SATA has been involved in a number of major national and international projects in areas including satellite communications, navigation, remote sensing, and testing. SATA also pays attention to the transformation of scientific and technological research and development results, the company's R & D personnel account for 74%, owns 139 intellectual property rights in related professional fields, and has now served customers across Europe, Asia and Africa.

• All the products have passed ISO9001 international quality system certification

• Ground station antenna can access INTELSAT, CHINASAT network, can be used in government, radio and television, energy, emergency and other fields

• Can provide circular polarization or linear polarization feed system; Turntable drive form can be selected according to user needs: manual or electric and other diversified customized solutions

• The antenna has better side lobe and higher gain by using antenna reflector shaping technology

• The pedestal and fasteners adopt the "three prevention" technology, so that the antenna has the characteristics of anti-mold, anti-moisture and anti-salt spray

• High performance-price ratio and reliable after-sales service guarantee: provide users with installation guidance and remote technical support

• Size: 1.8 m (5.9 ft), 2.4 m (8 ft), 3.0 m (10 ft), 3.7 m (12 ft), 4.5 m (15 ft), 5.3 m (18 ft), 6.2 m (20 ft), 7.3 m (24 ft), 9.0 m (30 ft), 11.3 m (38 ft), 13 m (43 ft) 16 m (52.5 ft)

ELECTRICAL SPECIFICATON
Band	C-Band		Ku-Band
Operating Frequency. GHz	Receive	Transmit	Receive	Transmit
	3.4～4.2	5.85～6.725	10.95～12.75	13.75～14.5
Gain, Mid-band, dBi	44	47.3	53.2	54.3
Polarization	Linear/Circular		Linear
XPD(on Axis), dB	35	35	35	35
XPD across 1dB Beam Width, dB	33	33	33	33
Axial Ratio (Circular-Polarized)	1.30/1.06	1.09/1.06
VSWR	1.25	1.25	1.25	1.25
Antenna Noise Temperature      10°Elevation 30°Elevation 50°Elevation	34°K 24°K 21°K		52°K 41°K 37°K
-3dB Beam Width, Mid-band        -3dB	1.12°	0.72°	0.37°	0.33°
Typical G/T(El ＞10°)                G/T	25.9dB/K° (30°LNA)		32.3dB/K (70°LNA)
Tx.Power Capability. KW		5		2
Feed Interface	CPR-229G	CPR-137G	WR-75	WR-75
Feed Insertion Loss, dB	0.2	0.2	0.25	0.25
Isolation, Tx to Rx, dB	90		85
First Sidelobe 90﹪ Peaksunder Following Envelop	-14 29-25logθ(1°≤θ＜20°)		-14 29-25logθ(1°≤θ＜20°)



About Cases



SATA has successfully delivered hundreds of sets of fixed station, gateway station, terminal station and calibration station antennas of different sizes to domestic and foreign users：



Design and construction of 13 m Ka band satellite ground station antenna



Customized 6.2 m antenna for a Italian company



About Qualification



SATA has：

• ISO 9001 Quality management system certification

• ISO 14001 Environmental management system certification

• ISO/IEC 20000-1 Service management system certification

• ISO 45001 Occupational health and safety management system certification

• ISO 19600 Compliance management system certification







About Exhibition



By participating in key international satellite exhibitions such as CABSAT Dubai Communications Show and Asia Tech x Singapore International Communications Show, SATA is committed to bringing cost-effective products and solutions and better services to every customer.







About Manufacture



SATA can meet customer`s requirements through mature supply chain systems, as well as professional production and development capabilities.







About Logistics



SATA provides customizable packaging, global logistics coverage and reliable service to more than 100 regions and countries on five continents.







We offer our customers a better choice with our endeavor and expertise.
